K386-T9

We only produce the best kitchen appliance and keep innovating only for you to have a quality life


  • Deep canopy collects smoke

Unique design of two-stage 140mm length deep canopy is beyond traditional tower-shape one, which is perhaps the most perfect in the word. "Bernoulli's Effect", golden roof design and the optimum aerodynamic layout, which exhausts more clean with more smoke collection.

  • Super-strong Suction

Over 20m3/min super-strong suction is far more than the current industry standards 17 m3/min, which is more suitable for kitchen with strong-suction.

  • Super Large Wind Pressure

Equiped with broadband adaptive motor, pressure smart intelligent reinforcing system, and automatically sensing the public flue pressure changes, adjusting turbine speed, thoroughly solves the problem for high-level residential public flue jams and smoke backflow.

The thrid generation dual-wing turbocharger has maximum pressure up to 400pa. The larger pressure, the stronger suction is.

  • Super Silent

The natioal post-doctoral research centre of De&E and Xi'an Jiaotong University took three years to develop the first sonic flight impeller.

Enjoy "quiet" space in kitchen with effictvie noise reduction to <=53 dB.

  • Integrated with Cabinet and Range Hoode

325mm depth shield is matching perfectly with the standard cabinets.

Integration with cabinet and range hood creates fashionalbe living space.


Body Inox Aisi 304
Levels Of Speed 3 Speeds
Minimum Airflow ≥1,110M3/H
Noise Level ≤53dB
Motor Type Full Sealed Metal Motor
Fan Type Metal Fans with Teflon Finish
Control Type Electronic Switch
Filtration Type Patented S.S Mesh Filter
Grease Flitering Rate 90%
Odor Reduction Rate 97%
Wind Pressure(Pa) ≥400
Illumination 2*2W LED
Venting Size 180mm
Product Size 895x515x658(WxDxH)(mm)
